Application example: Siemens S7-200 SMART compatible system (based on W5500 module)
Based on the STM32F103RCT6 core board, Add one TCP/IP communication (W5500), an S7-200 SMART compatible system is added.
14
Components
Hardware components
WIZnet - W5500
x 1
Project description
Basic Information Based on the STM32F103RCT6 core board, on the basis of the minimum system, an S7-200 SMART compatible system is added. Add one TCP/IP communication port, and the TCP/IP communication port is mounted with PPI protocol. Add one RS485 communication port, and the RS485 communication port is mounted with PPI protocol. Open the software STEP 7-MicroWIN SMART on the computer, and try to connect compatible systems via Ethernet and USB/PPI multi-host cables respectively. video download No Experimental hardware STM32F103RCT6 core board (1 piece) [ purchase ] : CH340E communication…
