Remote Relay Controller, NC400 RJ45 W5500 Remote Control Panel 12V-24V Power Control Equipment

Feature:

1. Remote control panel supports three modes including UDP mode, TCP client mode and TCP host mode.
2. W5500 chip is used for stable and quick response to network data packets, which is efficient.
3. There are 4 relay outputs, 4 LED indicator lights and 4 relay status, the corresponding indicator lights indicate the closing of the corresponding relay.
4. Entitled with pratical adoptability, relay controller's high quality can keep its high performance for a long time.
5. After many inspections before leaving the factory, power control equipment's quality is guaranteed, you can use it with confidence.

Specification:

• Item Type: Remote control panel
• Color: 1# Black / 2# White (optional)
• Input Voltage Power Range: 12V ~ 24V
• Control Level Input: 5V
• Relay Withstand Voltage: 10A / 250VAC 10A / 30VDC
• Initial Network Configuration:
• For Gateways Parameter: 192.168.18.1
• Subnet Code: 255.255.255.0
• Actual Address: bc.5f.f6.00.74.32
• Machine IP Address: 192.168.3.102
• Machine Port Number: 5000
• Destination IP Address: 192.168.3.100
• Target Port Number: 4001
• Working Mode: UDP mode, TCP client mode, TCP host mode
