PIC18F56K42_W5500_SCPI

Components

Hardware components
W5500

WIZnet - W5500

x 1

WIZnet parts

Project description

This project presents an implementation of SCPI (Standard Commands for Programmable Instruments) communication using a Microchip PIC18F56K42 microcontroller and a WIZnet W5500 Ethernet controller. SCPI is a standardized command language used to control and query test and measurement instruments. The objective is to provide a functional example of integrating a PIC-based system with Ethernet connectivity for remote command and control applications. A notable aspect of this work is the hardware platform. While most W5500 examples are developed with STM32, AVR, or ARM-based MCUs, this project…
