PIGATOR Ethernet - a single module carrier with RTC and Ethernet

PIGATOR Ethernet - a single module carrier with RTC and Ethernet

WIZnet

Published April 26, 2023

Original author: tostmann · Germany

PIGATOR Ethernet - a single module carrier with RTC and Ethernet

Components

Hardware components

WIZnet parts

Project description

DETAILS PIGATOR Ethernet – a single module carrier with RTC and Ethernet by tostmann Raspberry A+ (green) driving the PIGATOR Ethernet This device can carry one PIGATOR module and has itself Ethernet connectivity and and Real-Time-Clock. And It is an Raspberry Pi extension w/ Ethernet, RTC and an additional PIGATOR module. powerful EIB/KNX server based on RPi A+ Specs: modified HAT outline: fits on all RPi models A/B A+/B+ 100Mbps Ethernet (WIZnet W5500) DS1338 RTC with super cap energy storage 1 slot for PIGATOR module stacking uplink header Installation : Install Guide Linux Kernel Driver…
