Pico-In-Out-over-WIZnet-Ethernet

Using the Raspberry Pico inputs and outputs over Ethernet with the WizNet W5500 Lite module and TCP Client-Server

Benjamin

Published May 03, 2024

166 UCC

11 WCC

31 VAR

2 Following

Original author: Tartatin8551Original source (new tab)

Pico-In-Out-over-WIZnet-Ethernet

Components

Hardware components
W5500

WIZnet - W5500

x 1

Raspberry Pi Pico

Raspberry Pi - Raspberry Pi Pico

x 1

WIZnet parts

Project description

Project Overview The "Pico-In-Out-over-Ethernet" project harnesses the capabilities of the Raspberry Pi Pico and the WizNet W5500 Lite module to control inputs and outputs over an Ethernet connection. This innovative system is structured around two primary components: a TCP client running on the Raspberry Pi Pico, and a TCP server based on a Qt framework. Technical Specifications Client Device: Raspberry Pi Pico Ethernet Module: WizNet W5500 Lite Communication: TCP Client-Server architecture Programming: C++ for hardware interaction, Qt for server interface System Architecture TCP Client…
