2040-ArtNode: RP2040 + W5500 ArtNet LED Controller Board
Open-source KiCad PCB design for a 4-universe ArtNet LED controller with RP2040, W5500, USB-C charging, and JLCPCB assembly support
0
Components
Hardware components
WIZnet - W5500
x 1
Raspberry Pi - RP2040
x 1
Python - Python
x 1
KiCad - KiCad
x 1
Project description
An ArtNet Controller Designed for Manufacturing Dan Newcome, a maker based in the USA, has published a complete open-source PCB design for an ArtNet LED controller built around the RP2040 and WIZnet W5500. Unlike most maker ArtNet projects that wire up an existing W5500-EVB-Pico on a breadboard or stripboard, this one is a custom board designed from the ground up for JLCPCB turnkey assembly. Every component in the BOM comes from the JLCPCB/LCSC catalog with matching part numbers, so you can order fully assembled boards without sourcing any parts yourself. The board drives four independent…
