RPi5- 2 Port Ethernet + PoE
RPi5- 2 Port Ethernet + PoE
2
Components
Hardware components
WIZnet - W5500
x 1
Raspberry Pi - Raspberry Pi 5
x 1
Project description
About Raspberry Pi 5 About Raspberry Pi 5 - HAT PoE The board is designed to use Ethernet using the WIZnet Chip. Of course, the existing Ethernet can also be used. In addition, the board is designed to use PoE+, which can be used not only through the WIZnet Connector but also through the existing Ethernet Connector. Hardware Connection The Raspberry Pi GPIO used inside W5500 is as follows. Getting Start W5500 Ethernet Raspberry Pi update Update the list of packages on the system with the following command. sudo apt-get update Install gpiod WiringPi is PRE-INSTALLED with standard Raspbian…
