Designing an Ethernet Module by Connecting a W5500 to an STM32H7 100-Pin MCU(Circuit Design Section)
Designing an Ethernet Module by Connecting a W5500 to an STM32H743VIT6
2
Components
Hardware components
WIZnet - W5500
x 1
STMicroelectronics - STM32H743VIT6
x 1
Project description
By chance, I stumbled upon a great opportunity to design a circuit with the STM32H743VIT6 MCU for the first time. (Is it really a great opportunity, though? Haven't tried it yet, so who knows?) Let's take a look at the STM32H743VIT6 product. Key Features of the STM32H743VIT6: Core: Arm® Cortex®-M7 processor, which can run up to 480 MHz, with double-precision floating point unit (FPU). Memory: Up to 2 MB of flash memory and up to 1 MB of RAM, providing ample storage for complex applications. High-Speed Interfaces: Includes USB OTG, Ethernet, and SDMMC. Rich Connectivity: Supports a wide range…
