Controllino Powered Irrigation Controller / Home Assistant

Project description

Software Apps and online services Home Assistant The circuit: Controllino Maxi - ATmega 2560-16AU with W5100 ethernet https://www.controllino.biz/product/controllino-maxi/ pinout: https://www.controllino.biz/wp-content/uploads/2018/10/CONTROLLINO-MAXI-Pinout.pdf CONTROLLINO customized bootloaders https://github.com/CONTROLLINO-PLC/CONTROLLINO_Library/tree/master/Bootloaders/MAXI W5100 ethernet (Built-In) 12V PoE Active splitter Adapter, to power Controllino 12V Electric Solenoid Valve for Water Flyback diode: Vishay 50V 1A, Diode, 2-Pin DO-204AL 1N4001-E3/54 Inputs: Analog Capacitive Soil…
