Project description

🔍 1. Project Overview – KinCony AG8 The KinCony AG8 is an 8-channel Ethernet relay controller that integrates with ESPHome, allowing seamless integration with Home Assistant. Unlike Wi-Fi-based solutions, it uses wired Ethernet for communication, leveraging the WIZnet W5500 chip to ensure stable and low-latency networking. 🔧 2. Hardware Configuration (Focused on W5500) Component Description MCU ESP32 Ethernet Chip WIZnet W5500 (connected to ESP32 via SPI) Relays 8-channel mechanical relays Power Supply 12V DC input with onboard 3.3V/5V regulation I/O Physical buttons, GPIO expansion The…
