Esp32-C6-Bug

Improving Esp32-C6-Bug by Leveraging w5500 Ethernet Communication

WIZnet

Published November 02, 2023

Original author: allexoKOriginal source (new tab)

Components

Hardware components

WIZnet - W5500

x 1

WIZnet parts

W5500 Datasheet

Project description

DESCRIPTION Hello everyone, this project is about building a small development board with battery support around the Esp32-C6FH4. The Esp32-C6 is a quite interesting new low-power RISC-V MCU from Espressif with multi-protocol support (WiFi, Ble, Zigbee, Thread...). WiFi-6 further reduces power consumption. So making a board with battery charging and protection circuits seems like an obvious idea. The multi-protocol feature allows easy implementation of protocol bridges or dongles. Low-power consumption, along with battery support, gives users the opportunity to create things like Zigbee…
