Project description
•MCU :STM32H743IIT6 •SDRAM: 32M Bytes •External SPI FLASH:32M Bytes •2 Port Ethernet (PHY chip(LAN8720A) & W5500) •1* RS485 , 1* CAN , 1* RS232 •1* Single bus interface(Support IIC) •1 * micro-sd card •2 * MINI-USB (1 Serial to USB, 1 USB-Slave) •1 * USB-TYPEA , 1 * micro sim •GPRS & WIFI •1 * RGB-LCD interface
