Project description
W5500 WIZnet Ethernet Tests Applies to all boards and modules which use the WIZnet W5500 chip: WIZ850io, W5500 Shield, etc. Hardware used Teensy 3.2 Teensy 3.2 with ARM Cortex M4 Teensy 3.2 breakout board R3 at OSH park, essential to map Teensy 3.2 to a standard DIP-style pinout without the awkward bottom header and end pins. Systronix designed a simple assembly jig to help in assembling Teensy 3.2 to this adapter. PRJC WIZ820io & Micro SD Card Adaptor which also works with the WIZ850io module (850io and 820io are pin-compatible). To use this with Ethernet, the CS and DC signals need…
