W5500 Smart Ethernet Module

WIZnet

Published April 07, 2023

Project description

W5500 Smart Ethernet Module/SPI to Ethernet TCP/IP for UNO R3/MEGA2560 – Green + Silver This is a VAR product of W5500. Overview Beyond W5100; Features: High-speed SPI interface, easy to connect with any MCU; Support TCP / IP protocols: TCP, UDP, ICMP, IGMP, IPv4, ARP, PPPoE; Built-in 10 / 100Mbps Ethernet Physical Layer; Supports automatic response (full / half duplex mode); Multiple indicator signal output; It supports eight independent ports (Socket) simultaneous connections; 32K bytes of internal memory for TX / RX cache; Support sleep mode and wake from LAN; 3.3V operating voltage, I /…
