[Vysocan] Ethernet W5500 breakout

Ethernet W5500 breakout/breadboard @3V3 for Arduino and oher SPI

WIZnet

Published April 03, 2023

Original author: OpenHomeSecurityOriginal source (new tab)

[Vysocan] Ethernet W5500 breakout

Components

Hardware components

Project description

Ethernet W5500 breakout/breadboard @3V3 for Arduino and oher SPI Features Breadboard friendly upgrade from official Arduino shield. W5500 chip. Size 2.5 x 5 cm. Require 3.3V. Up to 80Mhz SPI. RJ45 jacks with integrated magnetics. ACT and LINK LEDs. Standard 0.1″ pin header with GND, 3V3, SS, SCK, MISO, MOSI, RST, INT pins. I have made this board to test W5500 chip as upgrade from W5200 for my gateway board Alarm / Automation. And it is working for me in other test cases as well. It is same design as original WizNet W550io, but does not have MAC address preprogrammed. Works with standard…
