ESP32-S3 Smart Display Portal with W5500 Ethernet and WS2812 LED Control

A comprehensive IoT display portal combining ESP32-S3 with W5500 hardware TCP/IP for stable ethernet connectivity, 4" TFT display, and addressable LED control

Benjamin

Published September 23, 2025

166 UCC

11 WCC

31 VAR

2 Following

Original author: wojtron2Original source (new tab)

ESP32-S3 Smart Display Portal with W5500 Ethernet and WS2812 LED Control

Components

Hardware components
W5500

WIZnet - W5500

x 1

ESP32

Espressif - ESP32

x 1

WS2812B LED Strip

DFRobot - WS2812B LED Strip

x 1

WIZnet parts

Project description

Introduction This project builds a wired display and LED control portal using an ESP32-S3 microcontroller, a WIZnet W5500 Ethernet Controller, a 4″ ST7796 SPI TFT display, and WS2812 LED strips. It favors wired reliability and low latency over Wi-Fi, making it ideal for dashboards, visual controllers, or industrial indicators. Planned extensions include HTTP/REST APIs, PC applications, and smart home integration. WIZnet Product Integration The WIZnet W5500 is connected to the ESP32-S3 via SPI and handles Ethernet communications through its hardware TCP/IP stack. With support for multiple…
