Uthernet II Snooper CDA

Uthernet II Snooper CDA

simons

Published August 02, 2023

29 UCC

11 WCC

3 VAR

Original author: ksherlockOriginal source (new tab)

Uthernet II Snooper CDA

Components

Hardware components
W5100

WIZnet - W5100

x 1

Project description

This is a Classic Desk Accessory to peek and poke at the Uthernet II/Wiznet w5100 registers. Slot 3 is assumed. Built with the SNASM assembler and snlink, sorry. Keys: C - Common registers 0 - Socket 0 1 - Socket 1 2 - Socket 2 3 - Socket 3 R - Receive buffer T - Transmit buffer Left arrow, right arrow - switch between pages Up arrow, down arrow - scroll through memory (RX/TX only) : - write memory. Esc - quit Q - quit Writing memory: Format is address : xx [xx ...] where xx is a hexadecimal byte and address is 8-bit or 16-bit hexadecimal. spaces are optional. For the socket registers, the…
