Design of Distribution Automation Terminal Based on DSP

The system use full-function hardware protocol stack chip W5100 of Wiznet Company and RJ45 port which
integrated network transformer

emimamanna

Published October 25, 2022

18 UCC

6 VAR

Original source (new tab)

Design of Distribution Automation Terminal Based on DSP

Components

Hardware components
W5100

WIZnet - W5100

x 1

Project description

I. INTRODUCTION As the completion of projects for upgrading power grids and the construction of smart grid, the management of 10KV distribution network becomes more and more important. We have to increase the process and communication ability of the FTU in order to reach the target of more than 98% reliability proposed by State Grid Corporation of China. In researching and designing FTU, FTU generally uses multi-chip CPU and off chip AD in the past, but with DSP technology becoming mature, the advanced digital signal processing techniques has been applied to the design of FTU in distributionโ€ฆ
