STM32F103 and W5500-based Ethernet monitoring system that displays button and switch status on an LCD and web browser in real time.

Aimee0

Published March 12, 2026

120 UCC

25 WCC

29 VAR

Original author: Zero3epoOriginal source (new tab)

BTNqwe

Components

Hardware components
W5500

WIZnet - W5500

x 1

WIZnet parts

Project description

Generated by ChatGPT πŸ“Œ Overview BTNqweλŠ” STM32F103 MCU와 WIZnet W5500 Ethernet 칩을 μ‚¬μš©ν•΄ λ²„νŠΌκ³Ό μŠ€μœ„μΉ˜ μƒνƒœλ₯Ό LCD 및 μ›Ή λΈŒλΌμš°μ €μ—μ„œ 확인할 수 μžˆλ„λ‘ λ§Œλ“  μž„λ² λ””λ“œ λ„€νŠΈμ›Œν¬ ν”„λ‘œμ νŠΈμž…λ‹ˆλ‹€. 이 ν”„λ‘œμ νŠΈμ˜ 핡심은 물리 μž…λ ₯ μž₯치의 μƒνƒœλ₯Ό ν˜„μž₯ μž₯λΉ„μ—μ„œλ§Œ ν™•μΈν•˜λŠ” 것이 μ•„λ‹ˆλΌ, Ethernet λ„€νŠΈμ›Œν¬λ₯Ό 톡해 원격 λΈŒλΌμš°μ €μ—μ„œλ„ 확인할 수 있게 ν•˜λŠ” κ²ƒμž…λ‹ˆλ‹€. λ‹¨μˆœ GPIO μž…λ ₯을 λ„€νŠΈμ›Œν¬ 기반 μƒνƒœ λͺ¨λ‹ˆν„°λ§ ꡬ쑰둜 ν™•μž₯ν–ˆλ‹€λŠ” μ μ—μ„œ WIZnet Maker용 UCC둜 μ˜λ―Έκ°€ μžˆμŠ΅λ‹ˆλ‹€. ν˜„μž¬ 곡개 자료 κΈ°μ€€μœΌλ‘œλŠ” μƒμš© μ œν’ˆλ³΄λ‹€λŠ” κ΅μœ‘μš©Β·ν”„λ‘œν† νƒ€μž… 성격이 κ°•ν•©λ‹ˆλ‹€. λ‹€λ§Œ ꡬ쑰 μžμ²΄λŠ” μ‚°μ—…μš© Remote I/O, μ„€λΉ„ μƒνƒœ λͺ¨λ‹ˆν„°λ§, μœ μ„  IoT λ…Έλ“œμ˜ 기초 ν˜•νƒœλ‘œ ν™•μž₯ κ°€λŠ₯ν•©λ‹ˆλ‹€. πŸ“Œ Features λ²„νŠΌΒ·μŠ€μœ„μΉ˜ μƒνƒœ 감지 STM32F103의 GPIO μž…λ ₯을 톡해 λ²„νŠΌκ³Ό μŠ€μœ„μΉ˜ μƒνƒœλ₯Ό κ°μ§€ν•©λ‹ˆλ‹€. μž…λ ₯ μ΄λ²€νŠΈλŠ” FreeRTOS μ„Έλ§ˆν¬μ–΄λ₯Ό μ΄μš©ν•΄ νƒœμŠ€ν¬ λ‹¨μœ„λ‘œ μ²˜λ¦¬λ©λ‹ˆλ‹€. LCD 기반 둜컬 μƒνƒœ ν‘œμ‹œ I2C LCDλ₯Ό 톡해 λ²„νŠΌ μƒνƒœ, μŠ€μœ„μΉ˜ μƒνƒœ, IP μ£Όμ†Œλ₯Ό ν˜„μž₯μ—μ„œ 직접 확인할 수 μžˆμŠ΅λ‹ˆλ‹€β€¦
