MEI Water and Wastewater Monitoring Device: ESP32U, W5500 Ethernet and Offline Logging

MEI's ESP32U water-quality monitor supports W5500 LAN or Wi-Fi, 16 DI, 8 DO, 4 AI, and at least 100 days of logging at 5-minute intervals.

matthew

Published October 26, 2026 · Updated November 10, 2026

Original author: Meigroup · VietnamOriginal source (new tab)

MEI Water and Wastewater Monitoring Device: ESP32U, W5500 Ethernet and Offline Logging

Project description

MEI 수질·폐수 모니터링 활용 장면을 설명하는 4:3 썸네일

Overview: Water Quality and Equipment State in One Monitoring System

A treatment facility needs both measurement history and equipment context. A changing water-quality reading may need to be considered alongside a pump fault, a level signal or a communication interruption. Collecting these signals together gives operators a more useful starting point for inspections.

MEI GROUP's Water and wastewater quality monitoring device (internal monitoring) collects data from external sensors, analyzers and equipment-status signals at water plants, wastewater treatment stations and related facilities. Its interfaces include 4–20 mA, RS485/Modbus RTU and digital inputs, with server transmission over LAN or Wi-Fi. Official product description.

The published hardware uses ESP32U processing and identifies W5500 for Ethernet. The practical audience is operators and integrators connecting field instruments to internal monitoring, historical analysis and alarms.

AI-generated conceptual water-treatment monitoring scene with field sensors and an instrument cabinet
Image source: AI-generated editorial illustration created with OpenAI image generation for this article. A generic application scene, not a photograph of an MEI installation or verified product wiring.

Components and Published Specifications

The manufacturer's hardware table specifies the following configuration. Hardware specifications and functions.

ItemManufacturer-published specification
Power supply24 VDC
ProcessorESP32U
Digital inputs16 channels, 0–24 VDC
Digital outputs8 channels, 24 VDC
Analog inputs4 channels, 4–20 mA
Offline memory16 MB; memory technology is not specified
Ethernet connectionLAN – W5500
Device configuration1 configuration switch
Status indication3 signal/operating-status LEDs

RS485/Modbus RTU and Wi-Fi support appear in the product description. Confirm output ratings, instrument capacity and environmental requirements for the supplied configuration; the public table does not provide their detailed limits.

From Field Signals to Local Records and Server Data

The functional flow is external instruments and equipment signals → analog, RS485/Modbus RTU or digital inputs → ESP32U-based acquisition and recording → W5500 LAN or Wi-Fi → server and Web/App.

Functional flow from water-quality instruments and digital signals through ESP32U processing to W5500 LAN or Wi-Fi

Diagram source: Original illustration created for this article from the MEI product specification and WIZnet documentation. Functional overview, not a PCB wiring diagram.

Match Each Signal to Its Interface

The listed sensor examples include pH, ORP, turbidity, dissolved oxygen, TSS, residual chlorine, conductivity, temperature and ammonium. These are external instrument applications. Select the probes, transmitters and analyzers needed for the actual measurement task.

InterfaceExample roleIntegration points
4–20 mA inputsRead water-quality sensor or transmitter outputsSensor supply, measurement range, signal scaling and calibration
RS485 / Modbus RTURead analyzers, meters and industrial instrumentsAddresses, serial settings, register maps, units and supported device count
0–24 VDC digital inputsCollect operating state, high/low level, pump faults and cabinet alarmsSignal type, input thresholds, wiring and status interpretation
24 VDC digital outputsProvide outputs for project-specific equipment integrationOutput type/current rating, load protection and supported control functions

The four analog channels do not establish simultaneous measurement of every listed parameter. Likewise, eight outputs alone do not define an automatic dosing algorithm or permit direct connection of motor power loads.

Keep Records During a Network Interruption

MEI states at least 100 days of local data storage at a five-minute recording interval. When the connection recovers, pending data automatically synchronizes to the server, supporting historical review around an outage. Data storage and synchronization.

Connected recording, local storage during interruption and synchronization after recovery, with the manufacturer's five-minute and minimum 100-day condition

Diagram source: Original illustration based on MEI's storage and synchronization description. The retention statement applies to the published five-minute recording condition.

For a deployment, confirm retention with the intended channel count and record format, together with timestamping, overwrite policy, duplicate handling and power-loss preservation.

W5500 Evidence and Technical Role

The current official hardware table identifies:

Ethernet connection: LAN – W5500

This is product-specific evidence for the published Ethernet configuration. ESP32U-based processing collects and records field measurements, while W5500 provides the wired Ethernet interface. W5500's own documentation describes its SPI host interface and integrated 10/100 Ethernet MAC/PHY. Manufacturer hardware table · Vietnamese original · WIZnet chip documentation.

In a LAN configuration using RS485 instruments, the device combines a field-instrument network with an Ethernet server connection. The product-specific board schematic and firmware driver are not published on the page, so actual use of W5500 hardware TCP/IP offload remains unverified.

Communication Paths: LAN, Wi-Fi and RS485

PathResponsibilityRelevant settingConditions to confirm
W5500 LANSend collected data to the server over EthernetFixed monitoring cabinets with network cablingIP configuration, cabling, server reachability and access policy
Wi-FiProvide a wireless server connectionMonitoring locations with suitable site wireless coverageCoverage, credentials, interference and recovery behavior
RS485 / Modbus RTUConnect field analyzers and measuring instrumentsDevices supplying register-based measurementsSerial settings, addresses, registers and device capacity

LAN and Wi-Fi as server connections and RS485 as the separate field-instrument connection

Diagram source: Original comparison based on the MEI product description, with explanatory installation considerations. LAN/Wi-Fi concurrent operation and automatic failover are not established.

LAN and Wi-Fi serve the server side; RS485 serves field instruments. Choose the server connection against site infrastructure and confirm its operational behavior separately from sensor configuration.

Compare Product Roles

ProductPublished roleComparison point
Water and wastewater quality monitoring deviceInternal water-quality/equipment-state collection with 16 DI, 8 DO, 4 AI and W5500 LAN or Wi-FiTreatment-facility measurements and local I/O requirements
Datalogger DTG.100Customer-specific flow and pressure logging with 4G connectivityDistributed flow/pressure points versus internal treatment monitoring
IoT Gateway MLDAggregation of field protocols for Cloud/SCADA with LAN/4GDirect I/O acquisition versus protocol aggregation

The comparison distinguishes equipment roles. The cited DTG.100 and MLD descriptions do not identify W5500.

MEI GROUP: Linking Field Equipment and Operations Software

MEI GROUP is a Vietnamese developer of IoT equipment and operations software for water facilities and industry. With an office and R&D operations in Ho Chi Minh City, it develops loggers, gateways, controllers, firmware and Web/App or SCADA systems. Its water activities extend across intake, treatment, pumping and distribution. Company profile · Products.

Company characteristicPublic exampleReader takeaway
Development around utility requirementsDTG.100 was developed for HUEWACO, with remote measurement/transmission settings and instrument configurationConsider adaptation to existing instruments and operating procedures
Dedicated chemical-management equipmentChlorScale DTG.700 monitors chlorine-cylinder weight, consumption and remaining quantity, with HMI/remote alerts and associated condition monitoringRelate measurements to replenishment and field inspections
Attention to data delivery after acquisitionThe Quảng Trị groundwater project describes reporting destinations, transmission status, logs and retransmission of missing recordsSpecify delivery records and recovery as part of monitoring operations

These are separate company examples. Their control functions, reporting arrangements and deployment details do not establish features or installations of this water-quality device.

Web/App Monitoring and Remote Operations

The product page lists live readings, operating-state views, charts, history searches, individual parameter thresholds, alarms and reports. Multiple devices and measurement points can be managed centrally. This connects field data to routine review, exception handling and internal assessment. Published platform functions.

MEI also offers project-specific changes to channels, signal types, communication protocols, interfaces, thresholds and software functions. Agree the actual accounts, included services, report formats, retention and support terms for the supplied package.

Sales Approach: Site Requirements and Custom Development

The product is offered through a quotation and engineering-consultation route. Its request-a-quote link leads to Zalo, giving customers a way to discuss instruments, installation conditions and software scope before supply. Product and quotation · MEI Zalo.

MEI's broader OEM/ODM offer covers customer-branded equipment, firmware and Web/App or Cloud systems, from prototypes and testing to production and software operations. Its factory-solution consultation starts with existing equipment, measurement points and control requirements, then proposes integration and expansion stages.

This creates a useful distinction for buyers: an equipment purchase, a site-integration project and a customer-brand development project have different delivery and maintenance boundaries. For repeated installations, agree which functions can be reused and which changes need additional engineering. Define who maintains sensor mappings, alarm settings and reports as equipment is added. The product's customization offer does not establish that all broader OEM services are included with one controller.

Define the Purchase Scope and Integration Sequence

  1. Define the measurements: Select the external probes, analyzers and equipment-state signals needed for internal monitoring.
  2. Confirm power and I/O: Match sensor supplies, analog ranges, DI levels and output loads to the supplied hardware.
  3. Configure field data: Set scaling, Modbus addresses/registers, units and timestamp definitions.
  4. Connect the server: Configure LAN or Wi-Fi and agree message formats, access/security settings, monitoring views and thresholds.
  5. Validate recording and recovery: Test the chosen logging interval, local storage, communication interruptions and backfill at the installation.
AreaConfirm in the quotation or integration documents
Supplied equipmentIncluded sensors, connectors, power supply, enclosure and installation accessories
Electrical and field interfacesInput/output ratings, protection, sensor scaling, RS485 settings and supported device count
Server integrationProtocol/API documentation, payloads, authentication, encryption and third-party server support
Records and operationRetention conditions, timestamps, retransmission order, duplicates and power-loss behavior
Commercial and support scopePrice, availability, lead time, platform fees, updates, warranty and maintenance responsibilities

Contact: support@meigroup.vn · +84 865 578 778 · Zalo. Obtain pricing and supply terms through an individual quotation. Contact source.

Related WIZnet Maker Projects

Related exampleComparison point
SmartIrrigationSystem · OriginalAn ATmega2560/W5500 irrigation example with flow and pressure sensors. Compare field measurement with equipment monitoring and control.
stm32f407-iot-gateway · OriginalAn open STM32F407/W5500 development example using Modbus RTU and MQTT. Compare its documented implementation with a commercial device's required integration documents.

Those projects use their own hardware, firmware and protocols. Their implementations do not establish this product's server protocol or driver behavior.

FAQ

Are water-quality sensors included in the controller?

The device collects external sensor and analyzer signals. Confirm the included probes, measured parameters, ranges and calibration arrangements in the quotation. The application list does not define a complete sensor package.

Will it retain 100 days of data during a network outage?

The manufacturer's stated condition is at least 100 days at a five-minute recording interval. Confirm other intervals and channel configurations, together with power-loss preservation and backfill behavior for the actual installation.

Sources

SourceInformation used
Official English product pageW5500 identification, ESP32U, I/O, power, memory, recording conditions and platform functions
Vietnamese product originalHardware table, sensor applications, customization and quotation route
WIZnet W5500 documentationChip interfaces and capabilities, separate from product firmware implementation
Company profile · HomepageBusiness scope, development activities and contact details
Product catalogueCompany equipment range
DTG.100Role comparison and utility-specific development
IoT Gateway MLDProtocol-aggregation role comparison
ChlorScale DTG.700Separate chemical-management equipment example
Quảng Trị groundwater projectSeparate data-delivery and recovery example
OEM/ODM servicesCustomer-brand equipment and software development scope
Factory solutionsRequirements-led consultation and phased integration
MEI ZaloOfficial quotation-consultation destination
SmartIrrigationSystem originalField-measurement and control comparison
STM32 gateway originalOpen development implementation comparison
