How to Achieve High-Speed Ethernet with W6300 on Raspberry Pi RP2350
Achieve 80+ Mbps Ethernet on RP2350 using WIZnet W6300 via QSPI with hardware TCP/IP offload for low MCU overhead.
0
Components
Hardware components
WIZnet - W6300-EVB-Pico2
x 1
Project description
Step 1: Understanding the Hardware The W6300-EVB-Pico2 is a Pico 2–style evaluation board built around the Raspberry Pi RP2350 and WIZnet’s W6300 hardwired TCP/IP Ethernet controller. The key design choice is the high-speed QSPI host interface, enabling 10/100 Mbps Ethernet with reported 80+ Mbps data rates while keeping MCU overhead low through a hardware TCP/IP Offload Engine (TOE). Core W6300 networking hooks called out in the source: Integrated 10/100 Ethernet PHY 8 independent hardware sockets 64KB total SRAM for socket buffering Dual-stack IPv4/IPv6 Wake-on-LAN and low-power modes…
