MODBUS TCP based I/O for 3D Printer automation
This project envisions a MODBUS TCP-based I/O controller tailored for 3D printers.
It would help to control various aspects of 3D printing.
3
Components
Hardware components
Seeed Studio - Grove - Universal 4 Pin Buckled 5cm Cable (5 PCs Pack)
Wires to 3D printer Main Board
Software Apps and online services
Project description
Introduction This project originates from the need to have external control on 3D printers apart from the Firmware / Execution already supported internally. One of the most common Industrial control protocols is MODBUS and its also supported over TCP. The same was chosen to implement the control of Relays. Additionally to send GCode commands to the 3D printer an Socket based TCP/IP to UART server has been envisioned. Assumptions Ethernet capability and DHCP Server is already present in the Network. Dual Relay board used is not actually connected to AC power of the 3D printer. However the…
