Development board Spartan-6

Components

Hardware components

Project description

DETAILS The Spartan-6 development board has a Wiznet W5300 which is an integrated Ethernet TCP/MAC/PHY Chip. The W5300 is a complete solution for simple & low cost 100Mbps network connectivity. It has internal physical layer, MAC layer and TCP/UDP/PPoE processor. Also, it has 128KB of SRAM FIFO Memory which is used for buffering transmitting & receiving packets. The block diagram is as shown below. FEATURE DESCRIPTION FPGA Spartan-6 XC6SLX9 from Xilinx • 16M bits of User Flash Ethernet W5300 from WIZnet • Hardwired TCP/IP Protocols: TCP, UDP, ICMP, Ipv4,,ARP, IGMPv2, PPPoE Ethernet • 8…
