Project-OVSG
A prototype solar station monitoring system using the WIZnet W5500-EVB-Pico and INA260 sensors to measure voltage and current and transmit the data over Etherne
0
Components
Hardware components
WIZnet - W5500-EVB-Pico
x 1
Project description
Project Overview Project-OVSG is a prototype system designed to monitor the status of a solar power station. It is based on the WIZnet W5500-EVB-Pico board and utilizes two INA260 sensors to measure real-time voltage, current, and power data for both the solar panel and system load. Currently, the data is output via Serial, with a structure suitable for future expansion to Ethernet-based communication. Hardware Configuration Component Description WIZnet W5500-EVB-Pico RP2040 MCU with built-in W5500 Ethernet controller INA260 (x2) I2C-based voltage, current, and power sensor GPIO 21, 22 Used…
