Simple IoT LED Control with W55RP20-EVB-Pico

viktor

Published May 07, 2025

168 UCC

20 WCC

42 VAR

Original author: Syamil SafuanOriginal source (new tab)

Components

Hardware components

WIZnet - W55RP20-EVB-Pico

x 1

Project description

🔧 Project Overview This tutorial guides users through setting up the W55RP20-EVB-Pico development board to control three LEDs via TCP commands sent over a wired Ethernet network. It's an excellent starting point for those interested in exploring IoT concepts, especially using Ethernet-based communication.Cytron Technologies Malaysia 🧩 Hardware Components To build this project, you'll need: W55RP20-EVB-Pico board 3x LEDs 3x 220Ω resistors USB Type-C cable Ethernet cable Jumper wires Breadboard (optional)How2Electronics+14Cytron Technologies Malaysia+14Cytron Technologies+14Adafruit Learning…
