How to Interface W5500 Ethernet Module with STM32 via SPI
In this tutorial, we’ll learn how to connect and configure the W5500 Ethernet module with STM32 using SPI.
0
Components
Hardware components
WIZnet - W5500
x 1
Project description
⚙️ STM32 + W5500 Ethernet Interface — Setup and Ping Test This project demonstrates how to connect an STM32 microcontroller to the WIZnet W5500 Ethernet module, configure the hardware and firmware, and perform a successful ping test to verify network connectivity. It’s a practical and beginner-friendly example for those exploring Ethernet communication on STM32 boards. 🧰 What the Project Covers Step-by-step setup of the W5500 module over SPI with the STM32 development board. Configuration of Ethernet parameters such as IP address, subnet mask, and gateway. Initialization of the W5500 driver…
