Let's use Google Speech to control the device

Use Google Speech-to-Text API to convert voice to text and then control the device.

Let's use Google Speech to control the device

Components

Hardware components


Project description

Overview

Google's Speech-to-Text is a simple API based on machine learning that applies a powerful neural network model. Convert your voice to a string using the google.cloud.speech library. The converted string communicates with the W5100S via MQTT and controls the NeoPixel.

Let's use Google Speech to control the device, Overview

Prepare

Google Speech-to-Text

Speech-to-Text is an API that is powered by Google's artificial intelligence (AI) technology. You send your audio data to Speech-to-Text, then receive a text transcription of your audio data in response. For more information about how to construct a Speech-to-Text request, see the requests page.

https://cloud.google.com/speech-to-text/docs/before-you-begin?hl=en

Enable Speech-to-Text on a project.

  • Make sure billing is enabled for Speech-to-Text.
  • Make sure your project has at least one service account.
  • Download a service account credential key.
Let's use Google Speech to control the device, Prepare




Connect Raspberry Pi

Let's use Google Speech to control the device, Prepare

Let's use Google Speech to control the device, Prepare


Check out our step-by-step guide:
How to set up your Raspberry Pi 4 for the first time



Connect W5100S-EVB-Pico

Let's use Google Speech to control the device, Prepare


W5100S-EVB-Pico is a microcontroller evaluation board based on the Raspberry Pi RP2040 and fully hardwired TCP/IP controller W5100S – and basically works the same as Raspberry Pi Pico board but with additional Ethernet via W5100S.







Setup Google API service

Setup Google API service


In this tutorial, you'll learn how to use the Speech-to-Text V1 API from a Python application by following these steps:

Select a Google Cloud project and enable the Speech-to-Text API.

  • Select a Google Cloud project and enable the Speech-to-Text API.

Set up authentication by creating a service account and downloading a key.

  • Set up authentication by creating a service account and downloading a key.

Create a sample application that transcribes an audio file to text.

  • Create a sample application that transcribes an audio file to text.

Estimated time to complete: To get started, click Start.

Creating a project on the Google Cloud platform

<step-1> Menu -> IAM & Admin -> Manage resources

Setup Google API service


<step-2> Go to the page [Manage Resources] and [+CREATE PROJECT] select.

Setup Google API service


<step-3> Enter a name for the project and press CREATE. This creates a project.

Setup Google API service


<step-4> Menu -> APIs & servuce -> Library

Setup Google API service


<step-5> [Cloud Speech-to-Text API] Find and click. [MANAGE] click

Setup Google API service

Setup Google API service


Create User Credentials

<step-1> [+CREATE CREDENTIALS] select and Service account click

Setup Google API service


<step-2> Enter a name for the account and press CREATE

Setup Google API service


<step-3> Verify that the service account has been created as follows:

Setup Google API service


Create API key

<step-1> Manage service accounts click. Enter the service account you just created.

Setup Google API service


<step-2> KEYS -> ADD KEY -> Create new key

Setup Google API service


<step-3> Press Create while selected as the JSON format.

Setup Google API service


<step-4> Move the created JSON file to the RPi directory.

Setup Google API service


<step-5> Now it's time to export the JSON file.

example)
pi@raspberry:~ $ export GOOGLE_APPLICATION_CREDENTIALS="KEY_STRING"
Setup Google API service








Getting Started

Raspberry Pi Setup

  • Connect the microphone to the RPi USB port and download the Google.spech library for the Google Speech-to-Text service.
pi@raspberry:~ $ pip install --upgrade google-cloud-speech

or

pi@raspberry:~ $ python3 -m install --upgrade google-cloud-speech
Let's use Google Speech to control the device, Getting Started

  • Next, download and run mosquitto because you will control the device through mqtt. To install the Mosquitto Broker enter these next commands:
pi@raspberry:~ $ sudo apt install -y mosquitto mosquitto-clients

To make Mosquitto auto start when the Raspberry Pi boots, you need to run the following command (this means that the Mosquitto broker will automatically start when the Raspberry Pi starts :)

pi@raspberry:~ $ sudo systemctl enable mosquitto.service

Now, test the installation by running the following command:

pi@raspberry:~ $ mosquitto -v
Let's use Google Speech to control the device, Getting Started

  • We will issue the data converted from Google STT to Text again in MQTT, so we will add the following command to the code. The Speech-to-Text and MQTT integrated source code is attached below.
mosquitto_pub -d -h mqtt_host -t mqtt_topic -m mqtt_msg

WIZnet W5100S-EVB-Pico setup

  • Installing CircuitPython

Install CircuitPython on Raspberry Pi Pico by referring to the link above.

https://learn.adafruit.com/getting-started-with-raspberry-pi-pico-circuitpython/circuitpython

  • Download the below uf2 file link on your computer

CircuitPython 7.3.3 link - DOWNLOAD

  • Setup WIZnet Ethernet Library

Copy the WIZnet library Into the lib folder inside the Raspberry Pi Pico. https://learn.adafruit.com/ethernet-for-circuitpython/circuitpython-setup

Before continuing, make sure your board's lib folder has at least the following files and folders copied over: https://github.com/Wiznet/RP2040-HAT-CircuitPython

adafruit_bus_device
adafruit_wiznet5k
adafrui_minimqtt
Let's use Google Speech to control the device, Getting Started

  • Setup NeoPixel Library

Copy the CircuitPython NeoPixel into the lib folder inside the Raspberry Pi Pico.

https://learn.adafruit.com/circuitpython-essentials/circuitpython-neopixel

adafruit_pixelbuf.mpy
neopixel.mpy
Let's use Google Speech to control the device, Getting Started

  • Install Programs

The following serial terminal program is required for MQTT Publish test, download and install from below links.

✔Tera Term

Before this, you should find the Raspberry Pi Pico COM port number from "Device Manager" on your PC.

Let's use Google Speech to control the device, Getting Started




Let's start Speech-to-Text control device

  • Paste code into code.py on your Raspberry Pi Pico and Save it. Press "Ctrl+D" on the terminal window. you can see the messages as follows
Let's use Google Speech to control the device, Getting Started

  • Execute wiznet_speak.py Python code. I have attached the sauce below
Let's use Google Speech to control the device, Getting Started

  • Let's shout "Hi Pico" into the mic
Let's use Google Speech to control the device, Getting Started


Rainbow Color

Let's use Google Speech to control the device, Getting Started

  • Let's put the color we want into the microphone
Let's use Google Speech to control the device, Getting Started


Color LED on

Let's use Google Speech to control the device, Getting Started
