A device will display live information for a local train station. It will show departures, and and disruptions.

alistair

Published July 07, 2024 · © MIT license (MIT)

WIZnet - Live Train

Components

Hardware components

LED Matrix 32x8 MAX7219

x 1

Software Apps and online services

Project description

This project is to create a small matrix display that will show train departure time in my lab. This is so we know when is a good time to leave for the train, and when the trains are delayed so I can stay in the warm and dry. Building the Display The display uses two common matrix moduled that are based around the MAX7219 LED driver. These drivers are driven by a controller based on an Arduino Pro Mini. Any information received through the Arduino serial and interfaces is stored and used to instruct the MAX7219 drivers using the SPI interface. The hardware is simple and can be soldered up…
