Watterot Lan-Bee

WIZnet

Published April 20, 2023

Original author: watterott · GermanyOriginal source (new tab)

Components

Hardware components

WIZnet - WIZ550io

x 1

Project description

Features WIZnet W5500 Ethernet Controller (10/100Mbps) Integrated IPv4 stack (TCP, UDP, ARP, ICMP, IGMP, PPPoE) SPI interface with 5V tolerant inputs XBee compatible Pinout Documents Schematics + Layout https://learn.watterott.com/bee-modules/lan/
