How to connect W5300 to STM32 via FSMC interface
A tutorial of making a STM32CubeIDE project for using Etherent Controller which is interfaced to MCU as an external memory.
3
Components
Hardware components
WIZnet - WIZ145SR-EVB
x 1
Project description
Story As W5300 supports only Parallel Bus Interface to Host MCU, connecting W5300 to STM32F103 MCU needs FSMC(Flexible Static Memory Controller) interface. I’ll show you here how to configure FSMC interface for W5300 and how to set up a loopback application as an example of TCP/IP communication using W5300 Configure FSMC In Pinout and Configuration Tab, select Connectivity->FSMC and. In FSMC Mode block, click “NOR Flash/PSRAM/SRAM/ROM/LCD 3”, select “NE3” on Chip Select, “SRAM” on Memory type, “10 bits” on Address, and “16 bit” on Data. In FSMC Configuration block, change Write operation to…
