CONTROLE DE ACESSO COM ARDUINO + RFID + ETHERNET
This project is an access control and management system for an employee.
1
Components
Hardware components
Arduino - Arduino Mega 2560
x 1
Arduino - Arduino Ethernet Shield
x 1
Project description
This project is an access control and management system for an employee. When a user approaches the RFID card, the hardware performs reading the card number and accesses the WebAPI validation. Components list: Arduino Mega 2560 Arduino Ethernet Shield Arduino Relay Shield * LM7805 voltage regulator. RFID Reader ID-12 Innovations RFID cards Switching power supply 12V x 3A LCD 40 columns x 4 lines (Can be used with 2-line LCD) Buzzer Power supply to tail Wires, terminal strips and termoretráteis for connection * The assembly of the relay shield was presented in the post Building a Relay Shield…
