C11-P04-F04-SE_RAMP

Project description

Project Summary (40–60 words) This project builds an emergency evacuation guidance system on ESP32-S3 that streams 640×480 MJPEG while delivering power and network over a single PoE Ethernet cable. A WIZnet W6100 offloads TCP/IP in hardware and uses high-speed SPI + DMA to reduce CPU load, stabilize FPS, and remove Wi-Fi dependency for fire-critical operation. What the project actually does (technical, 150–200 words) The firmware implements a dual-port web interface: an HTTP control server (default port 80) and an MJPEG streaming server (default port 81). The device can operate in a split…
