W5500ToMax2 Ethernet interface PCB
This handy little PCB that Howard Dutton designed allows you to put a hard wired ethernet connector in the same foot print as the ESP8266 commonly used for WiFi
0
Project description
You need to supply a Teensy 4.0 MCU and a W5500 ethernet module. I keep a limited supply of Teensy MCUs on hand. So check with me if inventory shows zero. You can also purchse the Teensy MCUs at this URL. https://www.pjrc.com/store/teensy40.html Related Link This is a useful link within the site. It contains information related to Teensy, so it should be helpful. I have attached links in the diagram for reference. Teensy to WIZ812 Ethernet Adaptor Kit Teensy-Only Wiznet Ethernet Library
