Imagine Dragons - Believer - Arduino Cover

We have used Arduino to control the push-pull solenoids. Arduino SD card shield is used to read MIDI files from SD card.

irina

Published October 12, 2022 · © Apache License 2.0 (Apache-2.0)

187 UCC

5 WCC

66 VAR

Original author: TeenenggrOriginal source (new tab)

Components

Hardware components

Arduino - Arduino UNO

x 1

Arduino - Arduino Ethernet Shield 2

x 1

Project description

Code, circuit and details ▶ https://teenenggr.com/2019/12/25/imagine-dragons-believer-arduino/ Believer drum cover is played using MIDI file, Arduino Ethernet shield is used to read MIDI files from SD card. we’re using 13 push pull solenoids to play the different sounds. and solenoids are controlled by relays. Schematic
