Interacting with Arduino UNO-ethernet Shield
This tutorial briefly presents how to interact with an Arduino UNO Ethernet shield.
10
Components
Hardware components
Seeed Studio - Grove - 8-Channel Solid State Relay
x 1
Arduino - Arduino UNO
x 1
Arduino - Arduino Ethernet Shield
x 1
Project description
This tutorial briefly presents how to interact with an Arduino UNO Ethernet shield. Very special thanks to Ed Wolf and Hour To Midnight – Room Escape Games in Portland, Oregon USA. for this excellent tutorial. Please check the following presentation and the attached files: You may need to build a circuit board or use a prototype shield for your inputs. The resisters are 10k ohm. This is used to pull the inbound pins to the ground (LOW). The other side of the switch is connected to the 5v supply to cause the inbound pin to go (HIGH) when pushed. This tells the Arduino that the button is…
