W5500CoB (ESoPe)

Project description

DETAILS A small “Connector-on-Board” Plug-In Module with W5500 chip + with 8pin 100mil distanced Pin-Headers ‘Breadboard friendly’ Footprint. The W5500’s SPI I/F and PHY I/F is free available. The vertical RJ45 for Top side connection. The W5500CoB Module is made by German company ESoPe. Here pictures of Top and Bottom side: The schematic is here: The Pinout and Dimensions of the Module in detail are here: In the WIZnet EU’s Blogполучить кредитную карту с плохой кредитной историей is a nice explanation about how to connect RJ45 and make a short test setup. Source…
