Graphical Data Display with Arduino and HTML5

Arduino-based projects use LCDs to show data, but this project instead uses webpage so that more details can be displayed in a graphical for

WIZnet

Published February 10, 2023

Original author: prabash kpOriginal source (new tab)

Graphical Data Display with Arduino and HTML5

Components

Hardware components

Project description

The project presented here includes four webpages coded in four .htm files, which are stored in a memory card and then hyperlinked with each other. A web server created by an Arduino Ethernet shield loads the requested webpage from an SD card memory device into the browser. The webpage issues AJAX requests to the web server at regular intervals to get input data. The web server responds with an XML file containing measured input values in appropriate tags. The webpage reads input values from the XML format using JavaScript and displays them in an appropriate diagram/chart coded with HTML5…
