Art-Net Node With Arduino
my project heavily relies on Matthias Hertel's shield project which is easily understandable, detailed so the real credit is due to him
3
Components
Hardware components
Arduino - Arduino UNO
x 1
Arduino - Arduino Ethernet Shield
x 1
Project description
Matthias Hertel’s shield Matthias Hertel’s DmxSerial library explanation Simple or Advanced First you have to decide you just want to make it work, for testing purposes, like on a breadboar, or make it as a final device. The difference is that if you want to use it on the go, I heavily suggest to include the isolated optocoupler and DC converter. If you wish to skip the protection, you can simply go from the Arduino pin 1 to the MAX485 / MAX481 / SN7517 ‘s DI pin. Also that way, the isolated DC/DC converter is can be skipped. Schematic The schematic is written down on Matthias Hertel’s site…
