[Re]LilyGo-W5500-Lite-WoL

Project description

✅ Project Overview: Wake-on-LAN IoT Dongle Based on W5500 This project utilizes the LILYGO T-Lite W5500 development board to implement a Wake-on-LAN (WoL) IoT dongle. Users can remotely power on a PC by sending Magic Packets via a web-based configuration interface, where they can enter Wi-Fi and Ethernet settings, as well as the MAC address of the target PC. 🧩 Hardware Architecture MCU: ESP32 (supports Wi-Fi and BLE) Ethernet Chip: WIZnet W5500, connected via SPI, enabling hardware-based TCP/IP offloading Display: 0.96" OLED screen (SSD1306, I2C interface) Pin Mapping: ETH_RST: GPIO 4…
