W5500 Ethernet PoE module

Project source: Cloned from W5500 PoE module

WIZnet

Published November 30, 2022 · © GNU Lesser General Public License version 3 or later (LGPL3+)

Original author: ToneArtSoundOriginal source (new tab)

W5500 Ethernet PoE module

Components

Hardware components
W5500

WIZnet - W5500

x 1

WIZnet parts

Project description

Description This module can handle Ethernet for your board (f.x. an Arduino), and give it 5V from passive Power over Ethernet (PoE). The module is not IEEE 802.3af/at compliant and using a usual PoE source (f.x. a PoE switch) will give +48V to the module and surely blow it. Requirements: Max 100 feet Ethernet cable Max 400 mA (the module itself will use just a few mA) The source of power at the other end of the Ethernet cable: must follow usual passive PoE (on cables 4&5 and 7&8). 12V or 9V if using a short Ethernet cable (12V with a short cable will make the 5V voltage converter next to the…
