Dig Into Raspberry‑Pi Pico Memory Internals: Complete Breakdown of ROM, SRAM and Flash
In‑depth introduction to RP2040 underlying memory architecture including ROM, multi‑bank SRAM, XIP external Flash and address‑mapping mechanism
0
Project description
【Preliminary Note】The original hardware example in this article was written based on the RP2040. The actual hardware used in this hands-on demonstration features the W55RP20 as the main controller chip. The circuit logic and UF2 flashing operation principles are universally applicable, with only the main controller model differing. The original chip model mentioned in the circuit descriptions below is provided for reference purposes only. Here we supplement several core "mapping" concepts, which are the foundation of memory access. Afterwards we explain memory‑mapping tables for memory and…
