How to Build an Industrial FPGA Network Stack with WIZnet W5500 on Verilog?
This Industrial IoT project uses Verilog FPGA logic to control a WIZnet W5500 through an 80 MHz SPI interface.
0
Project description
How to Build an Industrial FPGA Network Stack with WIZnet W5500 on Verilog? Summary This Industrial IoT project uses Verilog FPGA logic to control a WIZnet W5500 through an 80 MHz SPI interface. The FPGA implements initialization, socket scheduling, event handling, data movement, and fault-recovery state machines, while W5500 provides the 10/100 Ethernet MAC/PHY, hardwired IPv4 TCP/IP processing, eight hardware sockets, and 32 KB of packet memory. The architecture is suitable for deterministic data acquisition, industrial control gateways, machine monitoring, and multi-channel telemetry…
