Industrial Ethernet to Serial IoT Bridge: SCADA Integration

A novel design of an industrial DIN rail Power over Ethernet (PoE) to Serial device was developed based on WIZ750SR with SCADA integration.

WIZnet

Published February 15, 2023

Original author: mhanuelOriginal source (new tab)

Industrial Ethernet to Serial IoT Bridge: SCADA Integration

Components

Hardware components

Project description

DETAILS Story Abstract In this work, a Power over Ethernet device was designed with characteristics that makes it industrial grade capable. A DIN rail 3D enclosure was designed for completeness of the hardware. A new software module was developed for an existing SCADA open source solution, the software module allows the discovery and configuration of the device. The solution was tested using the modbus industrial protocol on a simulator and also on an industrial energy meter to finally highlight its configuration process and real usage. Introduction The WIZ750SR device is a complete solution…
