Home Office Smart Room Controller

Dinesh

Published March 02, 2021

4 UCC

1 VAR

Original source (new tab)

Components

Hardware components

teensy - Teensy USB 3.2 Development Board

x 1

ElectroPeak 0.96" OLED 64x128 Display Module

x 1

BME/BMP280

x 1

Omron Electronic Components LLC B3F Tactile Switch

x 3

10G00 Tactile Switch Cap Blue, 95CAP-010 Tactile Switch Cap Yellow & 10G08 Tactile Switch Cap Red

x 1

LED - Red, Blue & Yellow

x 1

WIZnet WIZ850io Ethernet

x 1

SparkFun Rotary Encoder Breakout - Illuminated (RG/RGB)

x 1

SparkFun LilyPad Rainbow LED (strip of 7 colors)

x 1

Resistor 100 ohm

x 6

Software Apps and online services

(H/W) Philips hue

x 1

Qty: 5

(H/W) Solid Single Core Tinned Copper Wire

x 1

Qty: 1

(H/W) SPC20043 Ethernet Cable

x 1

Qty: 1

(H/W) Ultrasonic Sensor - HC-SR04 (Generic)

x 1

Qty: 1

(H/W) USB-A to Micro-USB Cable

x 1

Qty: 1

(H/W) Wemo Mini WiFi Smart Plug

x 1

Qty: 1

(S/W) Arduino IDE

x 1

Version: 1.8.13

Project description

It contains a motion sensor that allows a person to walk into a space and it will automatically turn on the Hue LED light bulbs, display the temperate on the OLED display while allowing you to control their brightness with the encoder rotary knob. They also wanted to add ease and a energy efficient component. By using the Wemo outlets you can plug your most used/valued components and can control their on/off function with the press of a button. Their example features three buttons that each control a separate outlet which can be located anywhere in your home. So with the press of a button…
