25. W5100S/W5500+RP2040 Raspberry Pi Pico<Modebus TCP Server Example>

25. W5100S/W5500+RP2040 Raspberry Pi Pico<Modebus TCP Server Example>

ronpang

Published December 11, 2023

Original author: WIZnet HKOriginal source (new tab)

25. W5100S/W5500+RP2040 Raspberry Pi Pico<Modebus TCP Server Example>

Components

Hardware components

Project description

1 Introduction Modbus TCP protocol is a data communication protocol widely used in industrial automation, building automation, energy management and other fields. It is based on the TCP/IP network, encapsulates the Modbus protocol in the TCP/IP protocol stack, uses Ethernet as the physical layer, and implements communication between devices through TCP connections. W5100S/W5500 is an embedded Ethernet controller integrating a full hardware TCP/IP protocol stack. It is also an industrial-grade Ethernet control chip. This tutorial will introduce the basic principles, usage steps, application…
