A text-based Rust networking guide for W55RP20, based on Lihan’s original work, with UART debugging improvements and a MACRAW reference using cotton.

COMPONENTS Software Apps and online services

Mozzila Foundation -> Rust Foundation - Rust Programming Language (rustlang)

x 1

PROJECT DESCRIPTION

Overview

This document is based on the original W55RP20 Rust Embassy Guide written by Lihan and published on maker.wiznet.io:

https://maker.wiznet.io/Lihan__/projects/w55rp20-rust-embassy-guide/

The original guide demonstrates how to run Rust networking examples on the W55RP20-EVB-Pico board and is primarily presented in an image-based format.
This document rewrites the same content into a fully text-based guide, allowing all commands and steps to be copied and executed directly.

In addition to the original content, this updated edition includes:

A UART-based debugging approach proposed by Lihan, intended for environments where RTT or probe-based debugging is not available
A brief reference to MACRAW-based W5500 operation using cotton, added as an architectural reference for readers who want to understand lower-level networking composition

The goal of this document is to provide a practical, reproducible Rust networking guide for W55RP20, while preserving the intent of the original work and extending it with field-tested improvements.

Environment

OS: Windows 11
Board: W55RP20-EVB-Pico
Network: Ethernet with DHCP
Optional: USB–UART adapter (e.g. HW-417-V1.2)

Rust Installation and Update

Install Rust if it is not already installed:

winget install Rustlang.Rustup

Verify the installation:

rustc --version
cargo --version

Update rustup and the toolchain:

Install ELF to UF2 Converter (RP2040)

cargo install elf2uf2-rs

Clone Embassy Repository

git clone https://github.com/embassy-rs/embassy
cd embassy

Embassy uses rust-toolchain.toml to pin a specific Rust version.
This behavior is expected.

Locate the W55RP20 Example

embassy/examples/rp/src/bin/ethernet_w55rp20_tcp_server.rs

Add RP2040 Target

rustup target add thumbv6m-none-eabi

Build the Example

cd embassy/examples/rp
cargo build --release --target thumbv6m-none-eabi

Convert ELF to UF2

elf2uf2-rs target/thumbv6m-none-eabi/release/ethernet_w55rp20_tcp_server

Flash and Run

Hold the BOOTSEL button

Connect the board via USB

Drag the generated .uf2 file to the mounted drive

The board reboots and runs automatically

UART Debugging (Proposed by Lihan)

When RTT or probe-based debugging is not available, Lihan proposed using UART output for debugging.

Wiring

GP0 (TX) → USB–UART RX
GP1 (RX) → USB–UART TX
GND → GND

Terminal Settings

Baudrate: 115200
Data format: 8N1

Applying the UART Debug Patch

changes.diff file

diff --git a/examples/rp/src/bin/ethernet_w55rp20_tcp_server.rs b/examples/rp/src/bin/ethernet_w55rp20_tcp_server.rs
index b402029b5..ddde42d7d 100644
--- a/examples/rp/src/bin/ethernet_w55rp20_tcp_server.rs
+++ b/examples/rp/src/bin/ethernet_w55rp20_tcp_server.rs
@@ -1,9 +1,5 @@
 //! This example implements a TCP echo server on port 1234 and using DHCP.
 //! Send it some data, you should see it echoed back and printed in the console.
-//!
-//! Example written for the [`WIZnet W55RP20-EVB-Pico`](https://docs.wiznet.io/Product/ioNIC/W55RP20/w55rp20-evb-pico) board.
-//! Note: the W55RP20 is a single package that contains both a RP2040 and the Wiznet W5500 ethernet
-//! controller. This allows using an ethernet chip without external SPI.

 #![no_std]
 #![no_main]
@@ -19,6 +15,9 @@ use embassy_net::{Stack, StackResources};
 use embassy_net_wiznet::State;
 use embassy_rp::bind_interrupts;
 use embassy_rp::gpio::{Input, Level, Output, Pull};
+use embassy_rp::uart::{Uart, Config as UartConfig, Blocking};
+use static_cell::StaticCell;
+use core::fmt::Write;
 use embassy_rp::pio::{InterruptHandler as PioInterruptHandler, Pio};
 use embassy_rp::pio_programs::spi::PioSpi;
 use embassy_rp::spi::Spi;
@@ -35,6 +34,25 @@ bind_interrupts!(struct Irqs {
     PIO0_IRQ_0 => PioInterruptHandler<PIO0>;
 });

+static UART: StaticCell<Uart<'static, Blocking>> = StaticCell::new();
+
+fn format_ip_to_uart(uart: &mut Uart<'static, Blocking>, addr: Ipv4Addr) {
+    let octets = addr.octets();
+    let mut buf = [0u8; 16];
+    let mut pos = 0;
+    for (i, o) in octets.iter().enumerate() {
+        if i > 0 {
+            buf[pos] = b'.';
+            pos += 1;
+        }
+        let s = itoa::Buffer::new().format(*o);
+        buf[pos..pos + s.len()].copy_from_slice(s.as_bytes());
+        pos += s.len();
+    }
+    uart.blocking_write(&buf[..pos]).ok();
+    uart.blocking_write(b"\r\n").ok();
+}
+
 #[embassy_executor::main]
 async fn main(spawner: Spawner) -> ! {
     let p = embassy_rp::init(Default::default());
@@ -45,6 +63,20 @@ async fn main(spawner: Spawner) -> ! {
     let mut pio = Pio::new(p.PIO0, Irqs);
     let cs = Output::new(p.PIN_17, Level::High);

+    let uart = Uart::new_blocking(
+        p.UART0,
+        p.PIN_0,
+        p.PIN_1,
+        UartConfig::default(),
+    );
+    let uart = UART.init(uart);
+    uart.blocking_write(b"RUST embassy W55RP20 Example Start....\r\n").ok();
+
     let spi = PioSpi::new(
         &mut pio.common,
         pio.sm0,
@@ -89,12 +121,14 @@ async fn main(spawner: Spawner) -> ! {
     let config = embassy_net::Config::dhcpv4(Default::default());
     let resources = STACK_RESOURCES.init(StackResources::<2>::new());
     let stack = Stack::new(device, config, resources, seed);
+    uart.blocking_write(b"Waiting for DHCP...\r\n").ok();

     spawner.spawn(net_task(&stack)).unwrap();
     spawner.spawn(wiznet_task(runner)).unwrap();

     loop {
         if let Some(config) = stack.config_v4() {
+            uart.blocking_write(b"DHCP OK.....  \r\n").ok();
             let local_addr = config.address.address();
+            format_ip_to_uart(uart, local_addr);
             let mut rx_buf = [0; 1024];
             let mut tx_buf = [0; 1024];

@@ -102,6 +136,7 @@ async fn main(spawner: Spawner) -> ! {
                 &stack,
                 1234,
             );
+            uart.blocking_write(b"Listening on TCP:1234...\r\n").ok();

             loop {
                 let mut socket = TcpSocket::new(stack, &mut rx_buf, &mut tx_buf);
@@ -114,6 +149,7 @@ async fn main(spawner: Spawner) -> ! {
                         socket.accept(1234).await.ok();
                     }
                 }
+                uart.blocking_write(b"Client connected\r\n").ok();

                 let mut buf = [0; 1024];
                 loop {
@@ -123,6 +159,18 @@ async fn main(spawner: Spawner) -> ! {
                         Ok(0) | Err(_) => break,
                     };

+                    uart.blocking_write(b"Client ").ok();
+                    if let Ok(addr) = socket.remote_endpoint() {
+                        if let embassy_net::IpEndpoint::Ipv4(ipv4) = addr {
+                            format_ip_to_uart(uart, ipv4.addr);
+                        }
+                    }
                     info!("rxd {}", buf[..n]);

                     if socket.write_all(&buf[..n]).await.is_err() {
                         break;
                     }
                 }

                 socket.close();
             }
         }

         yield_now().await;
     }
 }

git apply changes.diff

This patch enables UART logs for startup, DHCP status, IP address, and TCP connection events.

MAC Address Configuration

In the example source code, set the MAC address as follows:

let mac_addr = [0x00, 0x08, 0xDC, 0x01, 0x02, 0x03];

Note on MACRAW Reference (cotton)

This document briefly references that a similar loopback configuration can be implemented using MACRAW mode with cotton, where the W5500 operates as a raw Ethernet device and is connected to a higher-level stack such as smoltcp.
This reference is provided for architectural understanding only.

Appendix: MACRAW Loopback Example using cotton (Reference)

Overview

In addition to the Embassy-based networking example,
a loopback (echo) implementation using W5500 MACRAW mode can also be built with cotton.

In this approach, the W5500 operates as a raw Ethernet device, and higher-level networking (IP/TCP) is handled by smoltcp.
This configuration is useful for understanding how Rust embedded networking can be fully decomposed and reassembled.

This section is provided as a reference only and is not part of the main build-and-run flow.

Where to Find the Actual Source Code

The cotton project already provides working examples that demonstrate:

W5500 operating in MACRAW mode
Integration with smoltcp
Packet-level control below the TCP/IP stack

The most relevant sources can be found in the cotton repository:

cotton/
 ├─ cotton-w5500/
 │   └─ examples/
 │       ├─ macraw-smoltcp.rs
 │       └─ ethernet-basic.rs

These examples show how the W5500 is exposed as a smoltcp::phy::Device and can be reused to implement a TCP loopback.

Loopback Structure (Conceptual)

A typical MACRAW-based loopback using cotton follows this structure:

Initialize W5500 in MACRAW mode
Provide a MAC address to the driver
Bind the driver to smoltcp Interface
Create a TCP socket
Echo received data back to the sender

Minimal Loopback Skeleton (Reference)

// Reference-only skeleton (structure focused)

let mac_addr = [0x00, 0x08, 0xDC, 0x01, 0x02, 0x03];

// Initialize W5500 in MACRAW mode let device = cotton_w5500::MacrawDevice::new(
    spi,
    cs,
    int_pin,
    mac_addr,
);

// Bind to smoltcp let mut iface = smoltcp::iface::Interface::new(
    config,
    &mut device,
    now(),
);

// Create TCP socket let mut socket = TcpSocket::new(rx_buffer, tx_buffer);
socket.listen(1234)?;

// Echo loop if socket.can_recv() {
    let data = socket.recv(|buf| (buf.len(), buf.to_vec()))?;
    socket.send_slice(&data)?;
}

This skeleton is intentionally incomplete and focuses on architecture, not copy-and-run usage.
For a complete working example, refer to the cotton repository examples listed above.

Positioning Note

Embassy example: recommended for immediate development and deployment
cotton MACRAW example: reference architecture for understanding raw Ethernet and stack composition

Reference

cotton project repository:
https://github.com/pdh11/cotton

Original W55RP20 guide by Lihan:
https://maker.wiznet.io/Lihan__/projects/w55rp20-rust-embassy-guide/
