STM32F103 Multi-Axis Motion Controller with W5500 Ethernet and Industrial I/O

An STM32F103VBTx board combining six isolated stepper axes, 16 sensor inputs, CAN/RS-485, relays, and W5500 Ethernet.

josephsr

Published July 31, 2026

Original author: cos90 · ChinaOriginal source (new tab)

STM32F103 Multi-Axis Motion Controller with W5500 Ethernet and Industrial I/O

Project description

Project Overview This project is a hardware-centric industrial motion-control board designed for multi-axis point positioning, automated production equipment, industrial manipulators, and coordinated machine control. The controller integrates an STM32F103VBTx MCU, six optically isolated stepper-driver interfaces, 16 sensor inputs, three relay outputs, CAN, isolated RS-485, and W5500-based Ethernet. The design separates logic, communication, motor-control, and high-power relay sections to reduce interference between control and execution circuits. The project is best classified as a robotics…
