How to Design an RTOS-Based Ethernet System with W5500 for Education and Makers?

This project showcases an RTOS-based embedded system using the WIZnet W5500 Ethernet controller on a Mikit platform.

chen

Published February 13, 2026

90 UCC

1 WCC

12 VAR

Original author: 懒惰的猪妖Original source (new tab)

Project description

How to Design an RTOS-Based Ethernet System with W5500 for Education and Makers? (교육 및 메이커를 위한 W5500 기반 RTOS 이더넷 시스템 설계 방법) Project Summary (51 words) This project showcases an RTOS-based embedded system using the WIZnet W5500 Ethernet controller on a Mikit platform. By combining hardware TCP/IP offloading with deterministic task scheduling, the system demonstrates professional-grade network architecture while remaining accessible for education and maker-level experimentation. Overall System Architecture Core Components Mikit Platform Educational embedded development board MCU running an…
