What the Project Does

Maven is not just a programmer—it is a network-connected debug probe.

Instead of using USB-only tools like ST-Link or CMSIS-DAP, this firmware turns a small embedded board into a standalone debugging server:

A host PC connects via TCP (Ethernet) or USB

The firmware runs a GDB server internally

It communicates with the target MCU via SWD/JTAG

It optionally exposes:

Telnet (UART bridge)

HTTP (configuration UI)

SWO trace streaming

Data Flow

GDB (PC)
   ↓ TCP (Ethernet)
W5500 (hardware TCP/IP)
   ↓ SPI
SAM4S MCU (Maven firmware)
   ↓ SWD/JTAG
Target Cortex-M MCU

This removes the need for middleware like OpenOCD—GDB connects directly to the device.

Where WIZnet Fits

The project uses WIZnet W5200/W5500 Ethernet controllers, typically via SPI.

Role of W5500 in This System

Handles TCP/IP stack in hardware

Provides up to 8 hardware sockets

Manages:

TCP retransmissions
Checksums
Buffering
Exposes a simple register interface over SPI
This is critical because:
The MCU is already busy with:
SWD/JTAG timing
Flash programming
RTOS inspection
A software TCP/IP stack (like LwIP) would increase:
CPU load
latency jitter
complexity

Why W5500 is a Good Fit Here

Deterministic networking (important for debug sessions)

Minimal RAM usage on MCU

Simple integration with Arduino-style Ethernet APIs or native drivers

Stable wired connection (better than Wi-Fi for debugging)

Implementation Notes

1. WIZnet Driver Integration

File: src/network/wiz5x00.c

/*
 * Driver for the Wiznet WIZ5200 and/or WIZ5500 Ethernet Controllers
 *
 * Compile with one or both of -DWIZ_5200=1 -DWIZ_5500=1.
 * If both are defined, driver will auto-detect the chip flavour.
 *
 * Works with on-chip TCP/IP stack, or MACRAW mode for LwIP support.
 */

Why this matters:

The driver supports both W5200 and W5500 transparently

Auto-detection allows the same firmware binary across hardware variants

Two modes:

Native mode → uses W5500 TCP/IP offload

MACRAW mode → bypasses it and feeds LwIP

2. Dual Network Stack Architecture

File: src/network/Makefile.inc

else ifdef MK_INCLUDE_WIZNET_NATIVE
    DEFINES += -DNETWORK_DEV_WIZCHIP=1
else ifdef MK_INCLUDE_WIZNET_LWIP
    DEFINES += -DNETWORK_DEV_WIZCHIP=1
    MK_INCLUDE_LWIP := 1
endif

Why this matters:

The firmware can switch between:

Hardware TCP/IP (W5500)

Software TCP/IP (LwIP)

This is rare and powerful:

Enables performance vs flexibility trade-offs

Makes the project a reference architecture

3. MACRAW Mode (LwIP Bridge)

File: src/network/wiz5x00.c

s->s_type = WIZ5x00_SREG_MR_P_MACRAW;
if (ws->ws_chip == WIZ_CHIP_5200)
    s->s_type |= WIZ5200_SREG_MR_MF;
else
    s->s_type |= WIZ5500_SREG_MR_MFEN;

wiz_command(ws, 0, WIZ5x00_SREG_CR_OPEN, WIZ5x00_SREG_SR_MACRAW, 100);

Why this matters:

Socket 0 is opened in MACRAW mode

W5500 becomes a raw Ethernet MAC

LwIP handles full TCP/IP stack

This shows:

W5500 is not just used as-is

It can be re-purposed depending on architecture needs

4. Socket Buffer Allocation

rx_size = WIZ5x00_BUFFER_SIZE_RX / ws->ws_nsockets;
tx_size = WIZ5x00_BUFFER_SIZE_TX / ws->ws_nsockets;

Why this matters:

W5500 has internal SRAM (32KB)

It is divided across sockets

Trade-off:

More sockets → less buffer per socket

Fewer sockets → higher throughput per connection

5. Hardware TCP Keep-Alive (W5500 Only)

wiz_sreg_write8(ws, sn, WIZ5500_SREG_KPALVTR, 10);

Why this matters:

Uses W5500 hardware keep-alive

No MCU intervention required

Improves:

connection stability

long debugging sessions

6. MAC Address Generation

File: sam4s4_wizchip.c

mac[0] = 0x6u;
crc = crypto_crc32(sn, sizeof(*sn));
memcpy(&mac[2], &crc, sizeof(crc));

Why this matters:

No factory MAC needed

Device generates unique MAC from serial number

Practical for small-batch hardware

Practical Tips / Pitfalls

Ensure SPI clock stability—W5500 timing issues can cause silent failures

Allocate socket buffers based on actual usage (GDB + Telnet + HTTP)

Prefer native mode unless advanced routing (LwIP) is required

Watch for shared reset lines (W5500 + display in this design)

Use hardware keep-alive to avoid stale debug sessions

Be careful with interrupt vs polling design—network latency can affect debugging responsiveness

FAQ

Why use W5500 instead of a software TCP/IP stack?

W5500 offloads TCP/IP entirely, reducing MCU load and ensuring deterministic behavior—critical for real-time debugging and SWD timing.

How does W5500 connect to the MCU?

Via SPI. Typical signals:

MOSI / MISO / SCK

CS (chip select)

RESET

optional INT (interrupt)

What exactly does W5500 do in this project?

It provides a hardware TCP/IP interface so the firmware can expose:

GDB server (TCP)

Telnet (UART bridge)

HTTP configuration UI
without implementing a full network stack in software.

Can beginners build this?

Not easily. You need:

ARM debugging knowledge (SWD/JTAG)

embedded networking basics

RTOS familiarity
Intermediate to advanced level.

How does this compare to Wi-Fi solutions?

Ethernet (W5500):

deterministic

low latency

stable for debugging

Wi-Fi:

higher jitter

more complex stack

less reliable for continuous debug sessions

Source

Maven Firmware (Steve C. Woodford, Maverick Embedded Technology Ltd.)

License: BSD 3-Clause
