🚀 WIZnet Launches W6300: High-Speed Ethernet in a Compact Form
We are excited to announce the official release of the W6300, WIZnet’s newest iEthernet chip that brings together high-speed performance, hardware TCP/IP offloading, and compact form factor—all optimized for today’s demanding embedded applications.
The W6300 is engineered to deliver up to 90 Mbps throughput via a high-speed QSPI interface, making it the fastest SPI-compatible chip in the WIZnet portfolio to date.
⚡ Up to 80 Mbps over QSPI — Ethernet Without the Bottlenecks
The W6300 sets a new benchmark in SPI-based Ethernet chips. By leveraging a Quad SPI interface, it achieves data transfer rates over 80 Mbps, allowing developers to design Ethernet-enabled systems with the speed of traditional parallel interfaces—without the complexity.
This makes the W6300 ideal for applications that require:
High-throughput data logging
Low-latency control systems
Multimedia and real-time streaming
Secure, stable networking in compact embedded devices
🔁 The W5300 Legacy, Reinvented
WIZnet’s W5300 chip has long been known for its high-performance capabilities, with an 8/16-bit parallel bus interface and robust TCP/IP hardware stack. However, the W5300 comes in a large 100-pin LQFP package, limiting its use in compact designs and requiring more complex PCB routing.
With the W6300, we’ve redefined performance for modern embedded systems:
Feature | W5300 | W6300 |
|---|---|---|
Interface | 8/16-bit Parallel Bus | High-Speed QSPI (80 MHz) |
Max Throughput | Up to 80 Mbps | Up to 90 Mbps |
Package | 100LQFP | Compact QFN48 / LQFP48 |
Socket Channels | 8 | 8 |
Protocol Support | IPv4 only | IPv4 & IPv6 |
The W6300 brings similar high-performance networking in a smaller, easier-to-integrate form, using SPI instead of parallel bus for greater design flexibility—especially for MCUs and compact layouts.
🔑 Key Features of the W6300
Hardware TCP/IP Stack
Offloads TCP, UDP, IPv4, and IPv6 processing from the host MCU for deterministic Ethernet communication.
QSPI Interface
Enables high-throughput performance while reducing CPU load and simplifying hardware integration.
8 Independent Hardware Sockets
Handle multiple connections simultaneously for advanced networking use cases.
MACRAW Mode
Offers direct access to Ethernet frames for protocol development or monitoring.
Compact Package Options
Available in QFN48 and LQFP48, suitable for small-form-factor products.
🛠 Ready for a New Generation of Products
The W6300 is ideal for:
Industrial controllers and HMIs
Smart IoT edge devices
Surveillance and NVR systems
Environmental monitoring and sensing nodes
Secure gateway and communication modules
It provides developers with a balance of speed, scalability, and design simplicity, enabling modern Ethernet-enabled devices without the constraints of bulky packages or parallel bus complexity.
📦 Now Available
The W6300 is now available for order through WIZnet’s global distributors. To support your development, we provide:
Datasheet & Hardware Design Guide
Evaluation Board Schematics
Driver Source Code & Examples
💬 Let’s Build the Future of Embedded Ethernet
With the W6300, WIZnet delivers a new level of performance and efficiency in hardware Ethernet connectivity. Whether you're designing your next high-speed IoT device or upgrading an existing system, the W6300 is ready to power your innovation.
🎁 Want to Try W6300 for Yourself?
We’re offering free samples to help you explore the full potential of W6300 in your own projects.
